EMERGENCY HIGH BAY BULKHEAD 10/15W 1000/1500LM 3HR NON-MAINTAINED IP65 6500K MANUAL TEST INTEGRAL LED - ILEMBH030

EMERGENCY HIGH BAY BULKHEAD 10/15W 1000/1500LM 3HR NON-MAINTAINED IP65 6500K MANUAL TEST INTEGRAL LED - ILEMBH030

Regular price £59.20 exc. VAT
Regular price exc. VAT
exc. VAT
Sale price £59.20

£71.04 inc. VAT
Sale Sold out
Shipping calculated at checkout.

The Integral LED Emergency Non-maintained Manual Test Bulkhead provides at least 3 hours of emergency illumination in the event of a power cut.Offering high lumen output and power selection options these high bay luminaires are ideal for warehouses, factories and other industrial settings. Supplied with a hinged gear tray, push fit connectors and cable entry knock-outs (top, sides and back) for standard 20mm conduit (glands not supplied), Besa box and rear screw mount fitting. A set of self-adhesive emergency legends is also included.

Product Feature 1:
3 Hour Emergency Illumination
Product Feature 2:
Hardwearing and weatherproof
Product Feature 3:
Non-maintained
Product Feature 4:
Push-fit connector for easy installation
Product Feature 5:
Supplied with self-adhesive Legend Set
Product Feature 8:
IK08
  • Application: Open Area
  • Barcode: 5055788234968
  • Category: Emergency
  • Range Name: Emergency Bulkhead
  • Product Type: Emergency Bulkhead
  • Product Body Finish: Matt white
  • Market Segment: Indoor and Outdoor Commercial, Industrial, Residential
  • Finish: Matt White
  • Warranty (Years): 5
  • Emergency Option: Integrated
  • Emergency Category: Bulkheads
  • Product Length (mm): 355
  • Product Depth (mm): 70
  • Product Width (mm): 110
  • Product Weight (g): 59
  • Optic: Polycarbonate diffuser
  • Material: Aluminium, Polycarbonate
  • Construction: Plastic
  • Bulb or Luminaire Shape: Rectangle
  • Luminaire Fixing: Ceiling, Wall
  • Mounting Type: Rear, Side, BESA, Canduit Cable Entry
  • Placement / Application: Indoor, Outdoor, General Lighting
  • Luminous Flux in Lumens (lm): 1500
  • Luminous efficacy (lm/W): 176
  • Correlated Colour Temperature (CCT) (K): 4000
  • Colour Temperature: 4000K - Cool White
  • Colour Temperature Name: Cool White
  • Beam Angle: 120
  • Colour Rendering Index (CRI): 80
  • Frequency Range (Hz): 50/60
  • Instant on (Less than 1 second): Yes
  • LED Size (mm): 2835
  • LED Type: Surface mounted device (SMD)
  • Lifetime (hours): 30000
  • Lumens in Emergency mode (lm): 1500
  • Switching Cycles: 15000
  • Useful Lumens (lm): 1500
  • Power Factor: 0.5
  • Voltage Range (v): 220-240
  • Amperage (mA): 50
  • Input Voltage (V): 220-240
  • Battery Configuration: Ni-Cd 1500mAh
  • Dimming: Non-Dimmable
  • Driver Included: Yes
  • Electric Current: AC
  • Emergency Battery Life (years): 3
  • Emergency Lumens (lm): 1500
  • Emergency Type: Non-Maintained
  • EN: EN-60598
  • LVD Certified: Yes
  • EN: EN-60598
  • LVD Certified: Yes
  • CE RoHS: Yes
  • EU Luminaire: L
  • Hg 0% (Mercury Free): Yes
  • IK Rating (Impact Protection): IK08
  • IP Rating (Ingress Protection): IP65
  • Lowest Operating Temperature (°C): -20
  • Maximum Operating Temperature (°C): 50
